Brand：BETA Lasermike
Beta LaserMike’s ActiveScan measurement system outperforms traditional stationary and motion-based diameter gauges used to measure cables with unique profiles. ActiveScan effectively monitors and controls the height and width of flat, sector, and special-shaped cables with the highest precision regardless of product alignment or angular rotation. Its unique, non-contact oscillating measurement method ensures repeatable accuracy, faster product changeovers, and higher productivity for greater profits.
Measurement Profile:?Height and width up to 40 mm (1.50 in)
Speed:?Any production line speed
Accuracy:?±0.001 mm (±0.000040 in)1
Stroke Speed:?0.5 – 4.0 sec
Stroke Length:?Up to 50 mm (1.97 in)2
Oscillation Angle:?Up to ±10 degrees2
1±0.02% of product size.?
2Longer stroke lengths for greater oscillation angle are available upon request.
